EW70
Product Description
- Single Seal
- Pusher Seal
- Balanced (k<1)
- Wave Spring design
- Independent on direction of rotation
PRODUCT FEATURES
- Non-Cartridge design
- Spring has self-cleaning effect
- Ideal for slurry with high operating pressure
- Short Installation length possible
- Ideal for standardization with ANSI Pumps
- Design with pumping ring possible for effective cooling
PERFORMANCE CAPABILITIES
- d1: 25 to 160 mm
- Pressure: p1= up to 25 bar
- Temperature: t = -20°C…+ 150°C
- RPM: 20 m/s
- Permissible Axial movement: ±0.5 mm
TYPICAL INDUSTRIAL APPLICATIONS
- Chemical Processing
- Pharmaceuticals
- Food and Beverages
- Petrochemicals
- Edible Oil Refineries
- Sugar and Distilleries
- Power Generation
MATERIAL OF CONSTRUCTION
- Stationary: Silicon Carbide (Q1)
- Seal Face: Carbon Graphite Antimony Impregnated (A), Carbon Resin Impregnated (B), Silicon (Q1)
- Secondary: TTV(M1), FKM(V), EPDM (E), FFKM (K),
- Springs: CrNiMo Steels (G).
- Parts: CrNiMo Steel (G)
